The FortiGate network appliances represent the enterprise firewall platforms. FortiGate is based on FortiASIC, a purpose-built integrated architecture, that provides extremely high throughput and exceptionally low latency, while delivering excellent security effectiveness and consolidation. Targeted at high-speed data centers and large enterprises, the FortiGate 3815D delivers high NGFW and intrusion prevention (IPS) performance along with high port density and dual power supply for maximum flexibility.
- Product Description Fortinet FortiGate 3815D-DC - NEBS - Enterprise Bundle - security appliance - with 5 years FortiCare 8X5 Enhanced Support + 5 years FortiGuard
- Device Type Security appliance
- Bundled Services 5 years FortiCare 8X5 Enhanced Support + 5 years FortiGuard
- Form Factor Rack-mountable - 3U
- Processor Fortinet FortiASIC CP8/NP6
- Hard Drive 960 GB
- Data Link Protocol 10 Gigabit Ethernet, 100 Gigabit Ethernet
- Performance Firewall throughput (1518-byte UDP): 320 Gbps ¦ Firewall throughput (512-byte UDP): 300 Gbps ¦ Firewall throughput (64-byte UDP): 150 Gbps ¦ IPS throughput: 30 Gbps ¦ Firewall latency (64-byte UDP): 5 µs ¦ Firewall throughput: 262.5 Mpps ¦ VPN throughput (IPSec): 135 Gbps ¦ VPN throughput (SSL): 10 Gbps ¦ SSL inspection throughput: 23 Gbps ¦ NGFW throughput: 20 Gbps ¦ CAPWAP throughput: 22 Gbps ¦ Application control (AVC) throughput: 44 Gbps ¦ Threat protection throughput: 13 Gbps ¦ IPS throughput (HTTP): 75 Gbps
- Capacity New sessions per second: 480000 ¦ Concurrent sessions: 95000000 ¦ Firewall policies: 200000 ¦ Gateway to gateway IPSec VPN Tunnels: 400000 ¦ Client to gateway IPSec VPN tunnels: 200000 ¦ Concurrent SSL VPN users: 30000 ¦ Virtual domains: 500 ¦ Number of FortiAP devices: 4096 ¦ Number of FortiToken devices: 5000 ¦ Number of FortiClient devices: 100000
- Included Accessories 2 SR SFP+ transceivers
- Power DC 48 - 72 V
- Power Redundancy Yes
- Dimensions (WxDxH) 17.4 in x 26.5 in x 5.2 in
- Weight 59.08 lbs
|
