Intel Next Unit of Computing Kit 9 Extreme Compute Element - NUC9I7QNB - card - Core i7 9750H 2.6 GHz - 0 GB - no HDD

Intel Next Unit of Computing Kit 9 Extreme Compute Element - NUC9I7QNB - card - Core i7 9750H 2.6 GHz - 0 GB - no HDD

  • Price:
    $832.99
  • Availability:
  • Mfr #:  BKNUC9I7QNB
  • UNSPSC #:  43211508
  • Item #:  008033358
  • Add to Shopping List
  • cnet cat code #:  1001010101
Need Help? Contact your Zones Account Manager or call 800.408.9663
Cache Memory
Installed Size 12 MB
Cache Per Processor 12 MB
Miscellaneous
Compliant Standards CISPR 24, ICES-003, EN55024, FCC Part 15 B, FCC Part 15 C, AS/NZS 4268, FCC Part 15 E, BSMI CNS 13438, REACH, EN 62311, EN 300.440, China RoHS, EN 300 328, EN 301 489-1, KN32, KN35, AS/NZS 2772.2, EN 301 893, IEC/EN/UL 60950-1, EN 55032, EN 301 489-3, EU RoHS, IEC/EN/UL 62368-1, EN 301 489-17, ARPANSA, Taiwan BSMI RoHS, AS/NZS CISPR 32, VCCI 32
Networking
Ethernet Ports 2 x Gigabit Ethernet
Ethernet Controller Intel I219-LM, I210-AT
Wireless LAN Supported Yes
Wireless NIC Intel Wi-Fi 6 AX 200
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Compliant Standards IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Dimensions & Weight
Width 8 in
Depth 1.5 in
Height 5.2 in
Audio Output
Sound Output Mode 7.1 channel surround
Compliant Standards High Definition Audio
Hard Drive
Type No HDD
Graphics Controller
Graphics Processor Intel UHD Graphics 630
Video Interfaces HDMI, USB-C
Max Monitors Supported 3
Monitor
Monitor Type None.
Storage Controller
Type 1 x SATA/NVMe
Controller Interface Type SATA 6Gb/s / PCIe 3.0 x4 (NVMe)
RAID Level RAID 0, RAID 1
Manufacturer Warranty
Service & Support Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature 32 F
Max Operating Temperature 95 F
General
Type Personal computer
Product Form Factor Card
Embedded Security Trusted Platform Module (TPM) Security Chip
Processor / Chipset
CPU Intel Core i7 (9th Gen) 9750H / 2.6 GHz
Max Turbo Speed 4.5 GHz
Number of Cores 6-core
CPU Qty 1
Max CPU Qty 1
Processor Main Features Intel Virtualization Technology, Intel AES New Instructions
Chipset Type Mobile Intel CM246
Expansion / Connectivity
Slots 1 (total) / 1 (free) x M.2 Card - 2242/2280 (SATA/PCI Express x4 (NVMe)) 1 (total) / 1 (free) x M.2 Card - 2242/2280/22110 (SATA/PCI Express x4 (NVMe))
Interfaces 4 x USB 3.1 Gen 2 - Type A (4 rear) 1 x HDMI 2 x LAN (Gigabit Ethernet) - RJ-45 2 x Thunderbolt 3/USB-C 3.1 Gen 2 1 x audio line-out - mini-jack / TOSLINK
Power
Device Type No power supply
RAM
Installed Size 0 GB / 64 GB (max)
Technology DDR4 SDRAM
Form Factor SO-DIMM 260-pin
Slots 2 (total) / 2 (empty)
Features Dual channel memory architecture
Optical Storage
Type No optical drive
