ELA SECURE FIREWALL 1220 APPL COMPACT ASA
ELA SECURE FIREWALL 1220 APPL COMPACT ASA
- Price:
$2,841.99
- Availability:
- Mfr #: CSF1220CX-ASA-K9
- UNSPSC #: 43222502
- Item #: 301566082
- Add to Shopping List
Need Help?
Contact Zones Online support at 800.408.9663
Miscellaneous
| Cables Included | 1 x console cable - 6 ft |
| Compliant Standards | UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, UL 62368-1, CAN/CSA-C22.2 No. 62368-1, EN 62368-1, IEC 62368-1, AS/NZS 62368-1, FCC CFR 47 Part 15 Class A, AS/NZS CISPR22 Class A, CISPR 22 Class A, EN 55022 Class A, ICES-003 Class A, VCCI Class A, EN 61000-3-2, EN61000-3-3, KN22 Class A, CNS 13438 Class A, EN 300386, TCVN 7189, EN55024, CISPR 24, KN24, TVCN 7317, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
Networking
| Form Factor | Desktop |
| Connectivity Technology | Wired |
| Data Transfer Rate | 1 Gbps |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Performance | Stateful inspection firewall throughput: 15 Gbps ¦ Stateful inspection firewall throughput (multiprotocol): 12 Gbps ¦ IPsec VPN throughput (450B UDP L2L test): 12 Gbps |
| Capacity | New connections per second: 250000 ¦ Concurrent firewall connections: 300000 ¦ Maximum VPN peers: 300 |
| Status Indicators | Link/activity/speed, management, alarm, system, power, SFP |
| Features | High Availability, reset button, 1 fan, auto duplex mode, auto-uplink (auto MDI/MDI-X) |
Manufacturer Warranty
| Service & Support | Limited warranty - replacement - 90 days - response time: 10 days |
Environmental Parameters
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 85% (non-condensing) |
General
| Device Type | Security appliance |
| Width | 6.8 in |
| Depth | 10.8 in |
| Height | 1.1 in |
| Weight | 3.09 lbs |
Processor / Memory / Storage
| Processors Installed | 1.6 GHz |
| RAM | 16 GB DDR5 SDRAM |
| Flash Memory | 16 GB |
| Hard Drive | SSD 480 GB x 1 - M.2 NVMe |
Expansion / Connectivity
| Interfaces | 8 x 1000Base-T - RJ-45 ¦ 2 x 1000Base-X/10GBase-X - SFP+ ¦ 1 x serial / console - RJ-45 ¦ 1 x management - RJ-45 ¦ 1 x USB 3.0 - Type A ¦ 1 x USB - Type C |
Power
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 32 Watt |
Software / System Requirements
| Software Included | Cisco ASA 9.22.1, Cisco Essentials |
