Wisenet 5 network indoor fisheye
Wisenet 5 network indoor fisheye
- Price:
$726.99
- Availability:
- Mfr #: XNF-8010RW
- UNSPSC #: 46171610
- Item #: 006263613
- Add to Shopping List
Need Help?
Contact Zones Online support at 800.408.9663
Interfaces
| Video | Composite video |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, PPPoE, IGMP, SSL, QOS, SSM, EAP, PIM-SM, SIP |
| Alarm Inputs Qty | 1 |
| Alarm Outputs Qty | 1 |
Miscellaneous
| Compliant Standards | IEEE 802.3af, IEEE 802.1x |
| Color | White |
Lens Construction
| Type | Fixed focal |
| Focal Length | 1.6 mm |
| Lens Iris | F/1.6 |
| Focus Adjustment | Automatic, manual |
| Min Focus Distance | 11.8 in |
| Horizontal Field of View (degree) | 192 |
| Vertical Field of View (degree) | 192 |
Image Sensor
| Type | 6 MP CMOS 1/1.8" |
| Total Pixels | 3096 x 2094 |
| Effective Pixels | 2048 x 2048 |
Environmental Parameters
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 131 °F |
| Relative Humidity (operating) | 0 - 90% |
General
| Device Type | Network surveillance camera |
| Audio Support | Yes: two-way audio capability, built-in microphone |
| Audio Formats | G.726, ADPCM, AAC-LC, G.711 |
| Form Factor | Dome |
| Connectivity Technology | Wired |
| Width | 5.7 in |
| Depth | 5.7 in |
| Height | 2.2 in |
| Weight | 25.75 oz |
Camera
| Type | Color - Day&Night - fixed - indoor |
| Video Format | NTSC, PAL |
| Digital Video Format | MJPEG, H.264, H.265 |
| Max Digital Video Resolution | 2048 x 2048 |
| Motion Detection | Yes |
| Digital Zoom | 8 |
| Exposure Range | 2 sec - 1/12000 sec |
| Minimum Illumination | 0.1 lux - color - F1.6 ¦ 0 lux - B&W - infrared LEDs on |
| Infrared LEDs | Yes |
| Infrared Distance | 49 ft |
| Video Capture | 2048 x 2048 @ 30 fps |
| Features | Backlight Compensation (BLC), progressive scanning, image flip, image mirror, Wide Dynamic Range (WDR), Motion Detection Technology, Privacy Mask Function, Samsung Super Dynamic Range (SSDR), Digital Image Stabilization (DIS), tamper-detection, digital PTZ function, fisheye lens, Quad PTZ Capture, 3D Noise Filtering, Variable Bitrate (VBR), Constant Bitrate (CBR), Audio Detection, Multicast Streaming, Defog, Smart Codec, auto gain control, auto white balance, ONVIF (Profile S) support, ONVIF (Profile G) support, loitering detection, 2D Digital Noise Reduction Technology, people counting, Pixel Counter Support, Heat Map, Samsung Super Noise Reduction (SSNRV), WiseStream II support, Directional Motion Detection, IP address filtering |
Expansion / Connectivity
| Ports | Composite video ¦ Audio line-in/microphone ¦ Audio line out - 3.5 mm mono jack ¦ USB ¦ LAN/power - RJ-45 |
| Supported Memory Cards | SD Memory Card, SDXC Memory Card, SDHC Memory Card |
Power
| Power Requirements | DC 12 V / PoE Class 3 |
| Power Device | 12 Watt |
Software / System Requirements
| OS Required | Microsoft Windows 7, Windows 8.1, Apple MacOS X 10.10, Windows 10, Apple MacOS X 10.11, Apple macOS 10.12 |
