- Product Description Cisco Catalyst 9500 - Network Essentials - switch - 12 ports - managed - rack-mountable
- Device Type Switch - 12 ports - L3 - managed - stackable
- Enclosure Type Rack-mountable 1U
- Subtype 40 Gigabit Ethernet
- Ports 12 x 40 Gigabit QSFP
- Performance Switching capacity: 960 Gbps ¦ Forwarding rate: 720 Mpps
- Capacity Indirect IPv4 routes: 64000 ¦ Host IPv4 routes: 32000 ¦ Indirect IPv6 routes: 32000 ¦ Host IPv6 routes: 16000 ¦ Multicast scale: 48000 ¦ QoS ACL scale: 18000 ¦ Security ACL scale: 18000 ¦ FNF entries: 512000 ¦ VLAN IDs: 4000 ¦ Switched virtual interfaces (SVIs): 4000
- MAC Address Table Size 64K entries
- Jumbo Frame Support 9198 bytes
- Routing Protocol OSPF, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, PIM-SSM, policy-based routing (PBR), RIPng
- Remote Management Protocol SNMP 1, RMON 1, RMON 2, SNMP, SNMP 3, TFTP, NETCONF, RESTCONF
- Features DHCP support, NAT support, PAT support, trunking, MPLS support, NSF, CBWFQ, WRED, STP support, VRRP support, ACL support, QoS, NSR, Rapid PVST+, RSPAN, HSRP support, VRF, MLD, FNF, MSDP, MACsec support, integrated Wireshark, VLAN Double Tagging (Q-in-Q), EoMPLS, H-VPLS, Private VLAN, L3VPN support, CoAP support, SPAN
- Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3ba
- Power AC 120/230 V (50 - 60 Hz)
- Power Redundancy Yes
- Dimensions (WxDxH) 17.5 in x 21.5 in x 1.7 in
- Weight 25.75 lbs
- Pricing Type Federal government
- Manufacturer Warranty Limited lifetime warranty
|
