AV LINE M4250-12M2XF 12X2.5G 2XSFP+ SWCH
AV LINE M4250-12M2XF 12X2.5G 2XSFP+ SWCH
- Price:
$1,118.99
- Availability:
- Mfr #: MSM4214X-100NAS
- UNSPSC #: 43222612
- Item #: 008228141
- Add to Shopping List
Need Help?
Contact Zones Online support at 800.408.9663
Miscellaneous
| Included Accessories | Mounting brackets |
| Cables Included | Console cable ¦ USB-C to USB-A cable |
| Rack Mounting Kit | Included |
| Compliant Standards | CCC, EN 61000-3-3:2013, EN 55024:2010, YD/T993-1998, IEC60950/EN60950, FCC CFR47 Part 15 B Class A, CNS 13438 Class A, GB 4943.1-2011, EN 55032:2012+AC:2013 Class A, CNS 14336-1, IEEE 1588, ICES-003:2016 issue 6 Class A, CISPR 32:2012, EN 61000-3-2:2014 Class A, VCCI-CISPR 32:2016 Class A, AN/NZS 60950.1:2015, AS/NZS CISPR32:2013 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, EN 60950-1:2006+A1:2010+A11:2009+A2:2013+A12:2011, GB/T9254-2008 Class A, ANSI C63.4:2014 |
| Localization | Americas |
Dimensions & Weight
| Width | 17.3 in |
| Depth | 3.9 in |
| Height | 1.7 in |
| Weight | 3.85 lbs |
Manufacturer Warranty
| Service & Support | Limited warranty - lifetime |
Environmental Parameters
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 90% (non-condensing) |
| Min Storage Temperature | -4 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 95% (non-condensing) |
General
| Device Type | Switch - 14 ports - L3 - managed |
| Enclosure Type | Side to side airflow rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 12 x 10/100/1000/2.5G + 2 x 10 Gigabit SFP+ |
| Performance | Switching capacity: 100 Gbps ¦ Firewall throughput (64-byte packet size): 74.4 mpps ¦ Latency (2.5 Gbps): 6.013 µs ¦ Latency (10 Gbps): 0.807 µs |
| Capacity | VLANs supported: 4093 ¦ ARP entries: 4000 ¦ Multicast entries (IPv4): 512 ¦ Multicast entries (IPv6): 128 ¦ Jumbo frame size: up to 12000 ¦ IGMP multicast groups: 2000 ¦ MSTP instances: 16 ¦ PVST instances: 32 |
| MAC Address Table Size | 16K entries |
| Routing Protocol | RIP, IGMPv2, IGMP, PIM-SM, PIM-DM, IGMPv3, PIM-SSM, static IPv4 routing, static IPv6 routing, MLDv2 |
| Remote Management Protocol | RMON 1, RMON 2, SNMP, RMON 9, Telnet, HTTPS, SSH, CLI, TACACS+, RADIUS |
| Encryption Algorithm | SSL 3.0, TLS 1.2 |
| Features | VLAN support, DoS attack prevention, sFlow, STP support, DHCP snooping, QoS, DHCP server, DAI, DHCP relay, LACP, RSPAN, GVRP, MVRP, 16MB packet buffer, IP source guard, BPDU, GMRP, STRG, policy based routing, AAA, LLDP-MED, Private VLAN, PIM, RSTP, LAG |
| Compliant Standards | IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1Qat, IEEE 802.1Qav |
| Processor | X ARM A9: 1.25 GHz |
| RAM | 2 GB |
| Flash Memory | 256 MB |
| Status Indicators | Link/speed |
Expansion / Connectivity
| Interfaces | 12 x 10/100/1000/2.5G RJ-45 ¦ 2 x 10GBase-X SFP+ ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 1 x console RJ-45 ¦ 1 x USB Type A ¦ 1 x console (USB) Type C |
Power
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Voltage Required | AC 110 V |
| Power Consumption Operational | 37.9 Watt |
| Power Consumption Stand by | 14.1 Watt |
