BUSINESS110SERIES UNMANAGED SW 24P GE PARTIAL POE 2X1G CBS110-24PP
  • Price:
    $320.99
« Back

BUSINESS110SERIES UNMANAGED SW 24P GE PARTIAL POE 2X1G CBS110-24PP

BUSINESS110SERIES UNMANAGED SW 24P GE PARTIAL POE 2X1G CBS110-24PP

  • Price:
    $320.99
  • Availability:
  • Mfr #:  CBS110-24PP-NA
  • UNSPSC #:  43222612
  • Item #:  008275337
  • Add to Shopping List
  • cnet cat code #:  10050201
Need Help? Contact Zones Online support at 800.408.9663
Miscellaneous
Included Accessories Mounting kit
MTBF 340,703 hours
Compliant Standards UL 60950, CSA 22.2, FCC CFR47 Part 15 A, FCC Class B certified
Localization United States, Canada, Mexico, Colombia, Chile, Latin America
Dimensions & Weight
Width 17.3 in
Depth 8 in
Height 1.7 in
Weight 6.57 lbs
Manufacturer Warranty
Service & Support Limited warranty - lifetime ¦ Technical support - web support - 1 year ¦ Technical support - phone consulting - 1 year
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
Humidity Range Operating 10 - 90% (non-condensing)
Min Storage Temperature -4 °F
Max Storage Temperature 158 °F
Humidity Range Storage 5 - 90% (non-condensing)
General
Device Type Switch - 24 ports - unmanaged
Enclosure Type Rack-mountable, desktop, wall-mountable
Subtype Gigabit Ethernet
Ports 12 x 10/100/1000 (PoE) + 12 x 10/100/1000 + 2 x combo Gigabit SFP
Power Over Ethernet (PoE) PoE
PoE Budget 100 W
Performance Forwarding performance (64-byte packet size): 35.7 Mpps ¦ Switching capacity: 48 Gbps
Capacity Buffer capacity (MB): 2
MAC Address Table Size 8K entries
Jumbo Frame Support 9216 bytes
Features QoS, Energy Efficient Ethernet, HOL blocking, WRR, loopback detection, Cable Diagnostics Function, auto-uplink (auto MDI/MDI-X), flow control, fanless, security slot (Kensington security lock compatible)
Compliant Standards IEEE 802.3az, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3af
Processor X ARM: 400 MHz
RAM 64 MB
Flash Memory 8 MB
Status Indicators Power, link/activity, PoE
Expansion / Connectivity
Interfaces 12 x 10/100/1000 Base-T RJ-45 PoE ¦ 12 x 10/100/1000 Base-T RJ-45 ¦ 2 x 1000Base-T / 1000Base-X RJ-45/SFP
Power
Power Device Internal power supply
Voltage Required AC 120/230 V (50/60 Hz)
Power Consumption Operational 135.67 Watt
