Samsung The Wall All-In-One IAB 146 2K IAB Series LED video wall - for digital signage
Samsung The Wall All-In-One IAB 146 2K IAB Series LED video wall - for digital signage
- Price:
$114,510.99
- Availability:
- Mfr #: IAB 146 2K
- UNSPSC #: 43211902
- Item #: 009896015
- Add to Shopping List
Need Help?
Contact Zones Online support at 800.408.9663
Connections
| Connector Type | DisplayPort ¦ 3 x HDMI ¦ 2 x USB 2.0 ¦ Audio line-out ¦ RS-232 input ¦ LAN |
Video Wall
| Resolution | 1920 x 1080 |
| Diagonal Size | 146" |
| Configuration | 16x12 |
Miscellaneous
| Compliant Standards | EMC Class A, IP20, TUV Rheinland Low Blue Light Certification, Safety 60950-1, Safety 62368-1 |
Audio System
| Speaker System | 2 channel |
| Output Power / Total | 10 Watt |
Environmental Parameters
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 80% RH |
General
| Product Type | LED video wall |
| Commercial Use | Yes - digital signage |
| Series | IAB Series |
| Operating System | Tizen OS 6.5 |
| HDR Capable | Yes |
| HDR Format | HDR10, HDR10+ |
| HDR Technology | HDR 10+, LED HDR, Micro HDR |
| Video Processor | Neural Quantum 4K |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Eco Sensor, temperature sensor |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| PC Interface | DisplayPort |
| Modes | DICOM Simulation Mode |
| Picture Enhancements | Dynamic Peaking Technology, AI Picture, Black Seal Technology, Ultra Chroma Technology |
| Width | 127 in |
| Depth | 1.9 in |
| Height | 71.4 in |
| Weight | 370.37 lbs |
Media Player
| USB Port | Yes |
| USB Ports Qty | 2 |
| Operating System | Tizen OS 6.5 |
Network & Internet Multimedia
| Connectivity | Wi-Fi, LAN, Bluetooth |
| Connect & Share | Samsung Smart View+ |
Video Wall Display Unit
| Pixel Pitch | 1.68 mm |
| Pixel Configuration | 1 red, 1 green, 1 blue |
| LED Type | Flip-chip RGB LED |
| LED Lifetime | 150000 hours |
| Maintenance | Front |
Dimensions & Weight (Shipping)
| Width (Shipping) | 78.7 in |
| Depth (Shipping) | 39.4 in |
| Height (Shipping) | 85.1 in |
| Weight (Shipping) | 663.58 lbs |
Power
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Video Wall Display Unit Power Consumption (Max) | 1240 W |
| Video Wall Display Unit Power Consumption (Typical) | 860 W |
| Heat Generation Details | Cabinet - max - 4231 BTU ¦ Cabinet - typical - 2934 BTU |
Display
| Frame Rate & Enhancement Technology | 100 Hz Refresh Rate, 120 Hz Refresh Rate, 7680 Hz Refresh Rate, Micro Motion |
| Color Temperature | 2800 - 10000K |
| Image Contrast Ratio | 22000:1 |
| Brightness | 1400 cd/m² |
| Viewing Angle | 170° |
| Viewing Angle (Vertical) | 155° |
| Additional Features | MagicInfo, 16-bit support, 20-bit processing |
