The FortiGate 4801F series enables organizations to build security-driven networks that can weave security deep into their datacenter and across their hybrid IT architecture to protect any edge at any scale.
Powered by a rich set of AI/ML-based FortiGuard services and an integrated security fabric platform, the FortiGate 4801F series delivers coordinated, automated, end-to-end threat protection across all use cases.
The integrated Zero Trust Network Access (ZTNA) enforcement within an NGFW solution, FortiGate 4801F automatically controls, verifies, and facilitates user access to applications delivering consistent convergence with a seamless user experience.
- Product Description Fortinet FortiGate 4801F - security appliance - with 5 years 24x7 FortiCare Support + 5 years FortiGuard Unified Threat Protection (UTP)
- Device Type Security appliance
- Bundled Services 5 years 24x7 FortiCare Support + 5 years FortiGuard Unified Threat Protection (UTP)
- Form Factor Front to back airflow rack-mountable - 4U
- Processor Fortinet FortiASIC CP9/NP7
- Hard Drive 2 TB x 2
- Data Link Protocol Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet, 25 Gigabit Ethernet, 200 Gigabit Ethernet, 400 Gigabit Ethernet
- Performance IPS throughput: 87 Gbps ¦ NGFW throughput: 77 Gbps ¦ Threat protection throughput: 75 Gbps ¦ IPv4 firewall throughput (1518-byte UDP): 3.1 Tbps ¦ IPv6 firewall throughput (1518-byte UDP): 3.1 Tbps ¦ VPN throughput (SSL): 18 Gbps ¦ SSL inspection throughput: 63 Gbps ¦ Application control throughput: 180 Gbps ¦ CAPWAP Throughput (HTTP 64K): 112 Gbps ¦ Firewall latency (64-byte UDP): 3.6 µs ¦ Firewall throughput: 1396 Mpps ¦ VPN throughput (512-bit IPSec): 800 Gbps
- Capacity Concurrent sessions: 280000000 ¦ New TCP sessions per second: 915000 ¦ Firewall policies: 200000 ¦ Gateway to gateway IPSec VPN Tunnels: 40000 ¦ Client to gateway IPSec VPN tunnels: 200000 ¦ Concurrent SSL VPN users: 30000 ¦ SSL inspection CPS: 60000 ¦ SSL inspection concurrent sessions: 30000000 ¦ Virtual domains: 10 ¦ Maximum virtual domains: 500 ¦ Number of FortiSwitches: 300 ¦ Number of FortiAP devices: 8192 ¦ Number of FortiAP devices (tunnel): 4096 ¦ Number of FortiToken devices: 20000
- Power AC 100-240 V (50/60 Hz)
- Power Redundancy Yes
- Dimensions (WxDxH) 17.1 in x 26.1 in x 6.9 in
- Weight 90.83 lbs
|
