Logitech Rally Bar Huddle plus Tap IP Video Conferencing Kit
Logitech Rally Bar Huddle plus Tap IP Video Conferencing Kit
- Price:
$2,499.00
- Availability:
- Mfr #: 991-000478
- UNSPSC #: 45111902
- Item #: 010742781
- Add to Shopping List
Need Help?
Contact Zones Online support at 800.408.9663
Audio Input
| Type | 6-microphone array - integrated |
| Microphone Operation Mode | Omni-directional, beamforming |
| Frequency Response | 90 - 16000 Hz |
Miscellaneous
| Cables Included | 1 x HDMI cable - 6.6 ft ¦ 1 x USB 3.0 Type C to Type A cable - 7 ft |
| Mounting Kit | Included |
| Compliant Standards | AES-128, FSC, CarbonNeutral |
Networking
| Connectivity Technology | Wired, wireless |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth LE |
| Network / Transport Protocol | IPv4, IPv6 |
| Features | Cable management, AES encryption, 128-bit encryption, Public Key Infrastructure (PKI), ARM TrustZone, Multicast Proxy support |
| Compliant Standards | IEEE 802.3af |
Manufacturer Warranty
| Service & Support | Limited warranty - 2 years |
Environmental Parameters
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% |
Input Device
| Type | 10.1" touchscreen |
| Connectivity Technology | Wired, wireless |
| Features | 1280 x 800 resolution, 14° display angle, VESA 100 x 100 mm |
General
| Device Type | Video conferencing kit |
| Kit Content | Logitech Rally Bar Huddle, Logitech Tap IP |
| Width | 21.6 in |
| Depth | 3 in |
| Height | 3.1 in |
| Weight | 3.97 lbs |
| Dimensions & Weight Details | Power adapter - Width 4.5 in Depth 1.9 in Height 1.3 in ¦ Touch screen - Width 9.7 in Depth 6.7 in Height 2.2 in Weight 2.2 lbs ¦ Video bar - Width 21.6 in Depth 3 in Height 3.1 in Weight 4 lbs |
| Enclosure Color | Graphite |
Video Input
| Type | Digital video camera (color) - desktop |
| Interface Type | SuperSpeed USB 3.0 |
| Digital Video Capture Resolution | 3840 x 2160 |
| Video Modes | 4K |
| Digital Zoom | 4 |
| Camera Mechanical Design | Pan / tilt / zoom |
| Features | Motorized privacy shutter, -48° / +48° pan, -32° / +32° tilt, 120° diagonal field of view, 113° field of view (horizontal), 80° field of view (vertical), Acoustic Echo Cancellation (AEC), Voice Activity Detector (VAD), microphone noise suppression technology, AI-powered |
Audio Output
| Type | Speaker(s) |
| Total Harmonic Distortion (THD) | <2% |
Expansion / Connectivity
| Interfaces | 1 x audio / video - HDMI input ¦ 1 x audio / video - HDMI output ¦ 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x USB 3.1 - 9 pin USB Type A ¦ 1 x USB-C 3.1 - 24 pin USB-C |
Power
| Power Device | Power adapter - external |
| Voltage Required | AC 100-240 V |
Software / System Requirements
| OS Required | Microsoft Windows 10 / 11, Apple MacOS |
