FORTIAP-234G OUTDOOR WIRELSS AP - TRI RADIO, WIFI 6E, INCLUDED, 2X 2.5
FORTIAP-234G OUTDOOR WIRELSS AP - TRI RADIO, WIFI 6E, INCLUDED, 2X 2.5
- Price:
$818.99
- Availability:
- Mfr #: FAP-234G-A
- UNSPSC #: 43222631
- Item #: 011361502
- Add to Shopping List
Need Help?
Contact Zones Online support at 800.408.9663
Internet of Things (IoT)
| Internet of Things (IoT) Compatible | Yes |
| Communications Technology | Bluetooth Low Energy (LE), Zigbee |
Miscellaneous
| Included Accessories | Pole/wall mount kit |
| MTBF | >10 years |
| Compliant Standards | EU Low Voltage Directive, RoHS, UL 2043, FCC, IP67 |
Networking
| Form Factor | Wall / pole mountable |
| Connectivity Technology | Wireless |
| Line Coding Format | OFDMA, BPSK, QPSK, 64 QAM, 256 QAM, 1024 QAM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth LE, ZigBee |
| Spread Spectrum Method | OFDMA |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Performance | Maximum throughput (2.4 GHz): 574 Mbps ¦ Maximum throughput (5 GHz): 1201 Mbps ¦ Maximum throughput (6 GHz): 2401 Mbps |
| Capacity | Maximum number of configured SSIDs: 24 ¦ Wireless clients per Wi-Fi radio: up to 512 ¦ Spatial streams: 2 |
| Status Indicators | Bluetooth Low Energy (BLE), Wi-Fi, LAN, power |
| Features | 2x2 MU-MIMO technology, auto-uplink (auto MDI/MDI-X), 802.1x authentication, Captive Portal, MAC black/whitelist, security slot (Kensington security lock compatible), Cellular Coexistence Filter (CCF), LED off mode, BSS Coloring, Target Wake Time (TWT), rogue AP detection, Wireless Intrusion Detection System (WIDS), Wireless Intrusion Prevention System (WIPS), Packet Sniffer Mode, spectrum analyzer, uplink/downlink MU-MIMO, iBeacon technology, reset button, Hit-less PoE Failover |
| Encryption Algorithm | WPA, WPA2, WPA3, WEP |
| Authentication Method | EAP-TLS, EAP-TTLS, MS-CHAP v.2, Extensible Authentication Protocol (EAP), PEAPv1, EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST, Radio Service Set ID (SSID) |
| Compliant Standards | Wi-Fi CERTIFIED 6E, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.3bt, IEEE 802.11d, IEEE 802.11e, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz |
Manufacturer Warranty
| Service & Support | Limited warranty - lifetime |
Environmental Parameters
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
General
| Device Type | Wireless access point |
| Ruggedized Design | Indoor, outdoor |
| Width | 8.5 in |
| Depth | 10.2 in |
| Height | 2.3 in |
| Weight | 3.04 lbs |
| Localization | Argentina, Aruba, Bahamas, Canada, Guam, Haiti, American Samoa, Bermuda, Cayman Islands, Dominican Republic, Marshall Islands, Nicaragua, Northern Mariana Islands, Palau, Saint Kitts and Nevis, Saint Lucia, Saint Vincent, Virgin Islands, Puerto Rico, United States |
Expansion / Connectivity
| Interfaces | 1 x 100/1000/2500Base-T (PoE++) - RJ-45 ¦ 1 x 10/100/1000Base-T (PoE ++) - RJ-45 ¦ 1 x console - RJ-45 ¦ 1 x USB - Type A |
Dimensions & Weight (Shipping)
| Shipping Weight | 8.16 lbs |
Power
| Power Over Ethernet (PoE) Supported | PoE++ |
| Power Device | Power injector |
| Voltage Required | AC 100-240 V |
Antenna
| Antenna | Internal |
| Antenna Qty | 10 |
| Directivity | Omni-directional |
