11AX 2X22 CLOUD MANAGED CEILING-MOUNT AP
11AX 2X22 CLOUD MANAGED CEILING-MOUNT AP
- Price:
$168.99
- Availability:
- Mfr #: ECW220
- UNSPSC #: 43222631
- Item #: 008029518
- Add to Shopping List
Need Help?
Contact Zones Online support at 800.408.9663
Miscellaneous
| Included Accessories | Wall/ceiling mounting kit |
| Compliant Standards | IC, FCC |
Networking
| Form Factor | External |
| Connectivity Technology | Wireless |
| Line Coding Format | CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, 1024 QAM, OFDMA |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Spread Spectrum Method | OFDMA |
| Remote Management Protocol | SNMP 1, SNMP 3, SNMP 2c |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Maximum throughput (2.4 GHz): 574 Mbps ¦ Maximum throughput (5 GHz): 1200 Mbps |
| Status Indicators | Power, LAN, 5 GHz, 2.4 GHz |
| Features | VLAN support, wall mountable, Spanning Tree Protocol (STP) support, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), SSH support, reset button, Management Information Base (MIB), ceiling mountable, MU-MIMO technology, packet aggregation A-MPDU, Management Information Base (MIB) II, Private MIB, packet aggregation A-SPDU, VLAN Tagging |
| Encryption Algorithm | AES, WPA2-PSK, WPA2-Enterprise, WPA3 |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.3af, IEEE 802.11e |
Manufacturer Warranty
| Service & Support | Limited warranty - 2 years |
Environmental Parameters
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 90% |
General
| Device Type | Wireless access point |
| Ruggedized Design | Indoor |
| Width | 6.3 in |
| Depth | 6.3 in |
| Height | 1.3 in |
| Weight | 13.47 oz |
Processor / Memory / Storage
| Processors Installed | 1 x ARM Cortex-A53 1 GHz |
| Max Supported Qty | 1 |
Expansion / Connectivity
| Interfaces | 1 x 1000Base-T (PoE) - RJ-45 |
Dimensions & Weight (Shipping)
| Shipping Width | 8.1 in |
| Shipping Depth | 8.1 in |
| Shipping Height | 3.3 in |
| Shipping Weight | 20.46 oz |
Power
| Power Over Ethernet (PoE) Supported | PoE |
| Power Consumption Operational | 12.8 Watt |
Antenna
| Antenna | Internal |
| Antenna Qty | 4 |
| Directivity | Omni-directional |
| Gain Level | 3 dBi |
